Selecting an appropriate range hood is an important step for your kitchen. Proper sizing and correct installation help maintain a cooking environment free from smoke and lingering food smells. The guidance below covers key points to consider when choosing and setting up your new venting unit.
A ductless range hood does not expel air to the exterior of the home. Instead, it draws cooking fumes into the unit and passes them through a filter designed to capture grease and odours. Installation is simpler compared to vented systems, but because there is no external exhaust path, it cannot fully eliminate smoke or cooking smells. In compact kitchens, an over‑the‑range microwave equipped with a built‑in ventilation fan can serve as a practical alternative.
A vented (or ducted) range hood functions by extracting cooking air and channelling it outdoors, either through an exterior wall or via the roof. Exhausting through an outside wall generally requires less waterproofing than a roof installation. If you opt for the roof route, it is essential that the duct runs all the way to the outside and terminates beyond the roofline—it should never end inside the attic. When directing the vent through an exterior wall, take care to avoid soffits or other structural obstructions that could block the airflow. While this type of system involves a more complex installation and a wider cost range, it offers significantly better performance in removing smoke and odours from the kitchen.
When selecting a range hood, the primary consideration is its width. It is advisable to choose a model whose width is at least as large as that of your cooking range. The performance of a ventilation unit is expressed in cubic feet per minute (CFM), which indicates the volume of air exhausted from the kitchen each minute. A common rule of thumb for determining the required CFM is to multiply the total floor area of your kitchen (in square feet) by two. This calculation provides a practical starting point for ensuring adequate airflow and effective removal of cooking by‑products.
For experienced DIY enthusiasts, this task is generally manageable, provided that the necessary tools and materials are on hand. However, it is important to note that mounting designs differ among manufacturers, so reviewing the specific installation guide supplied with your range hood is essential before starting any work.
If you are not confident in cutting through exterior walls or handling electrical connections, hiring a qualified installer is a prudent alternative.
Before any cutting or mounting begins, it is wise to confirm that the chosen wall area is free of hidden plumbing pipes or electrical cables. To do this, drill a small inspection hole first; if you encounter any utility lines, stop and call a qualified technician.
Next, determine the precise position for the exhaust opening. Take the hood’s physical dimensions and locate where its outlet sits, then transfer that reference point onto the interior wall.
Using an oscillating tool, cut the main opening for the vent. Making the hole slightly larger than required can give you extra working room and better visibility, and it also simplifies the process of routing the power cable from the hood to the junction box. Retain the cut‑out piece of drywall—it will serve as a template in the following step.
With a long drill bit, bore through the four corners of that template to the outside face of the house. Go outdoors, connect the four marks, and cut an opening sized for the vent pipe.
Now secure the exterior vent cap over that outside opening. Drive screws to hold it firmly, and apply caulk around the edges for a weathertight seal. If the cap overlaps multiple rows of lap siding, consider removing a square section of the siding and replacing it with a flat piece of PVC or wood to create a flush mounting surface.
At this stage, run the electrical supply line. Drill through any studs as needed to route the cable from the hood’s location to the electrical box. Once the cable is in place, strip the wire ends and join white‑to‑white, black‑to‑black, and the bare copper ground to its corresponding ground lead, using wire connectors; tuck the connections back into the junction box for safety.
Prepare the internal damper that came with the hood. Fit it roughly into the hole to gauge the available ducting space, then cut a short test length of duct and set it in position to confirm the clearance. Mark the outer edges of the damper on both sides so you know exactly where to apply foil tape later, then remove the damper temporarily.
Now install the damper properly. Remove the motor housing from the vent by unscrewing its fasteners. Insert the damper into the back of the hood, ensuring its orientation is correct, then secure it with screws. Seal all joints with HVAC foil tape to guarantee an airtight connection.
With the damper installed, position the hood against the wall with a helper’s assistance. Reach behind it to align the ductwork through the opening, press the unit flush, and centre it carefully. Mark the screw locations on the wall to indicate where the hood will be fixed.
Lower the hood again, and drive the mounting screws into the marked spots, leaving them ready for the final fit.
Re‑lift the hood and hang it onto the screws, adjust its position until the screw heads line up with the keyhole slots, then tighten them securely.
Complete the electrical connections inside the hood. Trim any excess cable, strip the conductors, and connect them again—white to white, black to black, and fasten the copper ground to the grounding terminal.
Finally, reinsert the fan motor into its housing, replace the filter, and the installation is fully finished.
